Getting Your App in the Internet¶

An Introduction to Infrastructure to Host Your App in the Internet

Presented By:

Frinze Lapuz, Snr. DevEx Software Engineer at Atlassian

Atlassian

What is Developer Experience (DevEx)?

Developer Experience is a particular specialization in the field of SE that focuses on making developers (human or agents) more productive and efficient.

The other way to see it is - DevEx is all about building the system that builds the system (primarily software). That system could include:

Tools to build the software
Culture of innovation in the Engineers that build software
(Or) Harnesses for the agents that build software (or as they call it in today's world - Agentic Software Engineering)

Goal¶

After this workshop, you will be able to:

Understand what's involved in hosting your app in the internet (from first principles)

Why are we learning from first principles?

First principle allows you to properly understand how each different parts of what we do connect with one another. When you know this first principle, whether you use AWS ECS, Google Cloud Run, Kubernetes, etc. - you'll be able to understand what it does under the hood enough for you to consider how that one particular tech handle the parts that we're doing in this workshop.

Prerequisites¶

Docker images already published in a public registry (eg. Docker Hub, Github Registry)
DigitalOcean Account
Domain name

What do you need to host your app in the internet?¶

Server (A computer that can run your server-side app such as Django or a "Static File App Server" to serve HTML, CSS, JS)
Domain Name
Your app 😄

sequenceDiagram
    Client Browser ->> DNS: my-app.codersforcauses.org
    DNS ->> Client Browser: 10.0.0.100
    Client Browser ->> Server: GET /
    Server ->> Server App: GET /
    Server App ->> Server: HTML, CSS, JS file / JSON response
    Server ->> Client Browser: HTML, CSS, JS file / JSON response

(Recommended to follow) A Simple Practical Example of a Server: Your Laptop as a Server for your Phone¶

This will not work in more complicated Networking

This is a simple example to help you understand the concept. This will not work for complicated networking such as the one that university has

Try turning on the hotspot of your phone
Connect your laptop to the hotspot
Create a simple html file with the content "Hello, World!" and name it index.html

<html>
    <body>
        <h1>Hello, World!</h1>
    </body>
</html>

Using the command below, serve the html file

python -m http.server 8000 # or any port you like

Confirm that when you go to http://localhost:8000, you see the "Hello, World!" message.

So far in this example - you have the server (your laptop) and the client (your laptop). Your browser requests the html file from the "localhost" address (also known as the "127.0.0.1" address).

Now let's get your phone accessing your laptop's server.

Run the command below to get your laptop's IP address

ipconfig # on Windows
ipconfig # on Mac
ip addr # on Linux

Your device can have multiple IP addresses

Your device can have multiple IP addresses. It depends on how many network interfaces your laptop has an how many its connected to.

Eg. if your device supports both WiFi and Ethernet, it will have two IP addresses. One for WiFi and one for Ethernet.

Mac it somewhat looks like this

$ ipconfig
...
en0: flags=8863<UP,BROADCAST,SMART,RUNNING,SIMPLEX,MULTICAST> mtu 1500
        options=6460<TSO4,TSO6,CHANNEL_IO,PARTIAL_CSUM,ZEROINVERT_CSUM>
        ether c8:89:f3:a9:47:9d
        inet6 fe80::c8f:ef7d:77d3:d776%en0 prefixlen 64 secured scopeid 0xf
        inet6 fd24:1169:9b10:1:886:2d84:cf22:81f5 prefixlen 64 autoconf secured
        inet6 2403:9e00:80a2:d700:1ca7:58a8:6721:5d0d prefixlen 64 autoconf secured
        inet6 2403:9e00:80a2:d700:55e8:36dd:acbc:5710 prefixlen 64 autoconf temporary
        inet 192.168.4.24  netmask 0xfffffc00 broadcast 192.168.7.255
        nd6 options=201<PERFORMNUD,DAD>
        media: autoselect
        status: active
...
en7: flags=8863<UP,BROADCAST,SMART,RUNNING,SIMPLEX,MULTICAST> mtu 1500
        options=6464<VLAN_MTU,TSO4,TSO6,CHANNEL_IO,PARTIAL_CSUM,ZEROINVERT_CSUM>
        ether 60:6d:3c:53:6a:76
        inet6 fe80::14d1:4da8:9a33:e016%en7 prefixlen 64 secured scopeid 0x18
        inet6 fd24:1169:9b10:1:1cc8:1137:aa39:47ac prefixlen 64 autoconf secured
        inet6 2403:9e00:80a2:d700:bf:9cc1:da56:d1fd prefixlen 64 autoconf secured
        inet6 2403:9e00:80a2:d700:4116:17ea:100e:8054 prefixlen 64 autoconf temporary
        inet 192.168.4.41 netmask 0xfffffc00 broadcast 192.168.7.255
        nd6 options=201<PERFORMNUD,DAD>
        media: autoselect (1000baseT <full-duplex>)
        status: active

Alternative for Mac

Your current Mac's IP address is viewable in Apple -> About this Mac ->System Report -> Network.

On your phone, go to the browser and type in the IP address you got from the previous step
You should see the "Hello, World!" message.

Fun fact: Mobile Development

If you're developing on mobile devices, and you want to test it live on your phone connected to your backend, this is somewhat the networking setup you'll need. The phone can talk to your laptop's server via the IP address you got from the previous step.

(Optional If you want to try...) Assigning a "Local Domain Name" to your laptop¶

On your laptop, create a file called hosts in the /etc/ directory
Add the following line to the file:

1	`127.0.0.1 my-app.local`

Restart the computer
Now when you go to your laptop and open the browser, you can type in http://my-app.local:8000 to access your app with the local domain name.

Side Story: Malaysia's Interactive Web App for Chinese New Year 2025 in Kuala Lumpur¶

Don't proceed yet until told :)

I got some fun stories for you! so hold on!

Intro

As an engineer working remotely, one of the amazing perks really is to travel and see the world in a daily life!

And of course because of that - back in 2025 I went to Kuala Lumpur it was great!

Exhibition

I went to this mall in the Petronas towers called "Suria KLCC". It looked like this!

One of the things I saw was this interactive web app.

Architecture

If you take a look at the architecture of the system, it will probably just look like this

"Push Architecture"

sequenceDiagram
    participant Ipad as Ipad
    participant ServerComputer as Server Computer
    participant DisplayComputer as Display Computer

    Ipad->>ServerComputer: Sent the Details about the Wish `/api/wish`
    ServerComputer->>DisplayComputer: (Via Push Notification) Send a request to `/api/display`
    DisplayComputer->>DisplayComputer: Change the display to the new wish

"Polling Architecture"

sequenceDiagram
    participant Ipad as Ipad
    participant ServerComputer as Server Computer
    participant DataStore as Data Store
    participant DisplayComputer as Display Computer

    Ipad->>ServerComputer: Sent the Details about the Wish `/api/wish`
    ServerComputer->>DataStore: Store the wish in the data store

    loop Polling
        DisplayComputer->>ServerComputer: Check if there's a new wish
        ServerComputer->>DataStore: Check if there's a new wish
        DataStore->>ServerComputer: Wish
        ServerComputer->>DisplayComputer: Display the wish
    end

Interactive Workshop Time: Taking it now to the cloud!¶

It is highly recommended that you follow along with the workshop

It is highly recommended that you follow along with the workshop. This will help you understand the concepts better because you'll get your hands dirty, see things for yourself!

Congratulations! You have successfully hosted your app already in your local network!

However, there's a couple of things now that you need to consider:

Your laptop is not always on
Your laptop is not always connected to the internet with the accessible IP address
Other devices don't know the "domain name" to get to your laptop.

In this workshop, we'll be focusing on hosting your app in the cloud.

Self-Hosting

If you're interested in what's involved in self-hosting, there's only really a couple of differences.

Firstly, you'll need to set your server up to always have power and always running. The next is, you'll need to configure your server to accessible in the public internet. Your router that you have will have an assigned public IP address. You just need to configure your router to do "port-forwarding" via private IP address to your server.

So imagine a layout a like this: - say your public IP address is 10.0.0.100 - the private IP address of your server is 192.168.1.100 - you need to configure your router to forward requests of port 8000 of 10.0.0.100 to 192.168.1.100

+----------------+        +----------------+
|                |        |                |
|     Router     |   -->  |     Server     |
|    10.0.0.100  |        | 192.168.1.100  |
|    8000        |        | 8000           |
+----------------+        +----------------+

With this case your website will now be accessible at http://10.0.0.100:8000.

For domain name, it will be the same as if you're in the cloud. You just need to configure your DNS to point to your server.

Getting a computer in the cloud¶

For this workshop, we'll be using DigitalOcean as our cloud provider.

You can use other providers such as AWS EC2, GCP Compute Engine, etc.

Login to DigitalOcean
Go to Droplet -> Create a new Droplet. Select these options
1. Region: Pick a region closest to you (for Perth - it will either be Singapore or Sydney)
2. Choose an Image: Go to "Marketplace" and search "Docker" (You'll probably find - "Docker latest on Ubuntu 22.04"). Choose that
3. Droplet Type: Just do Basic (but it's up to you)
4. CPU Options: Regular (Disk type: SSD). $6/mo (the lowest possible option) should be enough
5. Authentication Method: Select SSH Key - then add a new SSH key. Follow the instructions. If this doesn't work, please ask for help.
Once you've created the Droplet, you'll be able to see the IP address of the Droplet.
Connect to the Droplet using the SSH key you added.
1
ssh -i ~/.ssh/id_rsa root@<your-droplet-ip-address>
If you're using a passphrase, you'll be prompted to enter it.
1
Enter passphrase for key '/Users/USER/.ssh/id_rsa':
Once you're connected, you can start using the Droplet.

In my case - this is the command i ran

 ssh [email protected]
The authenticity of host '157.245.187.37 (157.245.187.37)' can't be established.
ED25519 key fingerprint is SHA256:WR5w09c9bLaCjCNGcvaAmgtTx3M1LzqsqGeG6LL36ew.
This key is not known by any other names.
Are you sure you want to continue connecting (yes/no/[fingerprint])? yes
Warning: Permanently added '157.245.187.37' (ED25519) to the list of known hosts.
Welcome to Ubuntu 22.04.5 LTS (GNU/Linux 5.15.0-153-generic x86_64)

 * Documentation:  https://help.ubuntu.com
 * Management:     https://landscape.canonical.com
 * Support:        https://ubuntu.com/pro

 System information as of Sun Jan  4 15:21:24 UTC 2026

  System load:  0.92              Processes:             112
  Usage of /:   5.6% of 77.35GB   Users logged in:       0
  Memory usage: 7%                IPv4 address for eth0: 157.245.187.37
  Swap usage:   0%                IPv4 address for eth0: 10.46.0.5
...

Why are we choosing from Market place, and not just go to OS?

In this workshop, we are wanting to use "Docker". We'd like it to preferably be preinstalled.

SSH Key Setup

At a basic case you'll do the following

Create a new key pair, if needed Open a terminal and run the following command:

1	`ssh-keygen`

You will be prompted to save and name the key.

Generating public/private rsa key pair. Enter file in which to save the key (/Users/USER/.ssh/id_rsa):

Next you will be asked to create and confirm a passphrase for the key (highly recommended):

Enter passphrase (empty for no passphrase):
Enter same passphrase again:

This will generate two files, by default called id_rsa and id_rsa.pub. Next, add this public key.

Add the public key

Copy and paste the contents of the .pub file, typically id_rsa.pub, into the SSH key content field on the left.

1	`cat ~/.ssh/id_rsa.pub`

For more detailed guidance, see How to Add SSH Keys to Droplets

Okay you now have a computer in the cloud!!! 🎉

Let's try serving just some hello world app!¶

Run the command below to run something in port 80

docker run --rm --name web-test -p 80:8000 crccheck/hello-world

Check if it's working using curl (a command-line tool that sends a request to a server, just like a browser does):

1	`curl http://localhost:80`

You should see the same "Hello World" text response printed directly in your terminal.

You can also check it from your own laptop's browser. Go to the browser and type in the IP address of the Droplet, followed by :80 (the port number) - for example http://<your-droplet-ip-address>:80. You should see

Hello World


                                       ##         .
                                 ## ## ##        ==
                              ## ## ## ## ##    ===
                           /""""""""""""""""\___/ ===
                      ~~~ {~~ ~~~~ ~~~ ~~~~ ~~ ~ /  ===- ~~~
                           \______ o          _,/
                            \      \       _,'
                             `'--.._\..--''

Now that's a demonstration of you serving something in the wider internet!

Let's add a Recognizable Domain Name to your app!¶

Where do you buy domain names?

You can buy it in multiple providers. If you want recommendations, Namecheap and Cloudflare are good options.

Cloudflare gives you an extra feature about protected DNS by doing "proxy" mode. This means that the IP address associated with the domain name is the IP address of the Cloudflare server. Only when the request is "allowed" (by your rules), the request is forwarded to your server, so you don't expose the IP address of your server to the wider internet.

Here's how it works:

sequenceDiagram
    participant Client as Client Browser
    participant DNS as DNS Server
    participant CF as Cloudflare Proxy
    participant Server as Your Server

    Client->>DNS: What's the IP for my-app.codersforcauses.org?
    DNS-->>Client: Cloudflare's IP (not your server IP)
    Client->>CF: GET my-app.codersforcauses.org (request)
    CF->>CF: Check security rules

    alt Request Allowed ✓
        CF->>Server: Forward request
        Server-->>CF: Response (HTML, JSON, etc)
        CF-->>Client: Response
    else Request Blocked ❌
        CF-->>Client: 403 Forbidden / Error Response
    end

    Note over Client,Server: Your actual server IP stays hidden! 🔒

Assuming you now have a domain name (or you're borrowing the codersforcauses.org domain name), you can now configure your DNS to point to your server.

Subdomains

For this workshop, we'll give you access to subdomains of codersforcauses.org. We are able to create as much subdomain for you.

You may want to create a subdomain for your app.

Borrow a CFC Laptop logged in to the Cloudflare DNS management page.

Create an "A" record for your subdomain pointed to your server's IP address.

1	`my-app.codersforcauses.org. IN A <your-server-ip-address>`

Save the changes.

Now you can access your app at http://my-app.codersforcauses.org.

Let's now focus on serving your backend and frontend!¶

What is Docker?

Docker is a way to package your application and its dependencies, so you can easily just run it. It's essentially a way to make your app "portable".

In the previous example, we just took some app in the internet and served it with just one command.

However, what we're about to do in this next section is going to use that same concept (while a bit more complex) to serve your backend and frontend.

For this workshop, I'm modelling the repository django-nextjs-template.

In this template, we publish two docker images:

Frontend: ghcr.io/codersforcauses/django-nextjs-template-prod-client (accessible here)
Backend: ghcr.io/codersforcauses/django-nextjs-template-prod-server (accessible here)

You will may have figured out that we have a "Production Compose Files". This production compose file is essentially used to model the docker container networking.

Getting the files onto your Droplet¶

Before you can run docker compose, you need the docker-compose.prod.yml file (and the other files it references, like the nginx config) on your Droplet.

The easiest way is to clone the whole repository onto your Droplet via SSH:

git clone https://github.com/codersforcauses/django-nextjs-template.git
cd django-nextjs-template

Using your own project instead

If you're deploying your own app instead of the example template, clone your own repository instead. Just make sure it has a docker-compose.prod.yml (or similar) file that references your own published Docker images.

Code of the compose

services:
db:
    image: postgres:16.4
    restart: unless-stopped
    volumes:
    - ./data/db:/var/lib/postgresql/data
    env_file: ./.env.prod
    healthcheck:
    test: ["CMD-SHELL", "pg_isready -U postgres"]
    interval: 3s
    timeout: 3s
    retries: 5

server:
    image: ghcr.io/codersforcauses/django-nextjs-template-prod-server:latest
    restart: unless-stopped
    env_file: ./.env.prod
    ports:
    - 8081:8081
    entrypoint: /entrypoint.sh
    volumes:
    - ./opt/accesslogs/:/var/log/accesslogs/
    - ./opt/static_files:/opt/static_files
    environment:
    - DJANGO_SETTINGS_MODULE=api.settings
    depends_on:
    - db

client:
    image: ghcr.io/codersforcauses/django-nextjs-template-prod-client:latest
    restart: unless-stopped
    env_file: ./.env.prod
    ports:
    - 3000:3000
    entrypoint: /entrypoint.sh
    depends_on:
    - server

nginx:
    image: nginx:stable-alpine3.21
    restart: unless-stopped
    ports:
    - 80:80
    - 443:443

    volumes:
    - ./docker/nginx/custom.conf:/etc/nginx/nginx.conf
    - ./opt/static_files:/app/static_files
    depends_on:
    - server
    - client

watchtower:
    image: containrrr/watchtower:latest
    restart: unless-stopped
    volumes:
    - /var/run/docker.sock:/var/run/docker.sock
    command: --interval 30

Reverse Proxy and Networking¶

Raw Nginx Configuration

user nginx;
worker_processes 1;
error_log /var/log/nginx/error.log warn;
pid /var/run/nginx.pid;

events {
    worker_connections 1024;
}

http {
    include /etc/nginx/mime.types;
    default_type application/octet-stream;

    # upstream to the server container
    upstream backend {
        server server:8081; #name of container:port exposed
    }

        # upstream to the server container
    upstream frontend {
        server client:3000; #name of container:port exposed
    }

    server {
        listen 80;
        server_name _;

        # proxy to api
        location /api/ {
            proxy_pass http://backend;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_set_header Host $host;
            proxy_redirect off;
        }
        # proxy to django admin
        location /admin/ {
            proxy_pass http://backend;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_set_header Host $host;
            proxy_redirect off;
        }
        # serve django static files
        location /static/ {
            alias /opt/static_files/;
        }
        # proxy to client
        location / {
            proxy_pass http://frontend;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_set_header Host $host;
            proxy_redirect off;
        }
    }
}

Visually here's what the networking looks like

                        CLIENT BROWSER
                              │
                   Request: my-app.domain.org
                              │
                    ┌─────────▼────────┐
                    │   VPS / Droplet  │
                    │  NGINX Reverse   │
                    │  Proxy:80/443    │
                    └─────────┬────────┘
                              │
              ┌───────────────┼────────────┬────────────┐
              │               │            │            │
          /api/*          /admin/*     /static/*      Default(/)
              │               │            │            │
         ┌────▼───┐      ┌────▼───┐   ┌───▼────┐  ┌───▼──────┐
         │Backend │      │Backend │   │Static  │  │Frontend  │
         │Docker  │      │Docker  │   │Files   │  │Docker    │
         │:8081   │      │:8081   │   │(disk)  │  │:3000     │
         │(Django)│      │(Django)│   │/opt/.. │  │(Next.js) │
         └────────┘      └────────┘   └────────┘  └──────────┘

This diagram shows:

Client Browser makes a request to your domain name (e.g., my-app.codersforcauses.org)
VPS/Droplet receives the request on port 80 (HTTP) or 443 (HTTPS)
NGINX Reverse Proxy inspects the request path and routes it:
/api/* → Backend Container (Django, port 8081)
/admin/* → Backend Container (Django, port 8081)
/static/* → Static Files served from disk (/opt/static_files/)
Default / → Frontend Container (Next.js, port 3000)

This setup allows you to serve both frontend and backend from a single domain name and port, with NGINX intelligently routing requests to the appropriate service.

Running your app!¶

Setup your .env.prod file. You can use the .env.prod.example file as a template.

1	`cp .env.prod.example .env.prod`

Now edit .env.prod and fill in the real values (eg. passwords, secret keys). You can use nano (simpler) or vi/vim (more powerful, usually already installed):

1	`nano .env.prod`

New to vi/vim? Here's a quick cheat sheet

vi/vim behaves differently to most text editors - it has separate "modes" for typing vs giving commands. If you accidentally open it and don't know how to get out, here's what you need:

1	`vi .env.prod`

Press i to enter Insert mode - now you can type/edit like normal
Press Esc to leave Insert mode and go back to Command mode
While in Command mode, type :wq then Enter to save and quit
While in Command mode, type :q! then Enter to quit without saving (if you messed up)

If you're ever stuck, press Esc first, then try one of the : commands above.

Check your docker-compose.prod.yml file to make sure it points to the correct images reference (this will change depennding on what the repo name you have).

Once everything is ready, run

1	`docker compose -f docker-compose.prod.yml up -d`

You should now be able to access your app at http://my-app.codersforcauses.org.

(Optional) CD (Continuous Deployment / Continuous Delivery)¶

So far we've setup the infrastructure to host your app. However, when you do software development professionally, you will write code all the time, and also make sure your code gets to production.

The process of automating how your code gets to production is called "Continuous Deployment" (sometimes it's referred to as "Continuous Delivery" in a "Product Engineering" context where each code change is a "deliverable").

Here's the complete pipeline:

sequenceDiagram
    participant Dev as Developer
    participant GitHub as GitHub
    participant Actions as GitHub Actions
    participant Registry as GitHub Registry
    participant Watchtower as Watchtower
    participant Server as Your Server

    Dev->>GitHub: Push code & create PR
    GitHub->>Actions: Trigger workflow (PR merged)
    Actions->>Actions: Build Docker image
    Actions->>Registry: Publish image

    loop Poll every 30 seconds
        Watchtower->>Registry: Check for new images
        Registry-->>Watchtower: New version found!
    end

    Watchtower->>Watchtower: Pull new image
    Watchtower->>Server: Start new container (blue-green)
    Server-->>Watchtower: New container healthy ✓
    Watchtower->>Server: Stop old container
    Server-->>Watchtower: Deployment complete ✓

In this workshop, we've setup "Watchtower" to automatically update your app when you push to the repository. How it works is essentially, whenever there's a new image pushed to the registry, Watchtower will pull it, start the container with the new image and stop the old one.

Because we know that the images pushed to the registry happens only when code is merged to the main branch, this means that whenever you merge your code to the main branch, your app will automatically be picked up and deployed to your server.

For small projects, watchtower is a great way to automate your deployment. However, for larger projects with more critical serving requirements, you may want to use a more sophisticated CD tool (such as AWS ECS), but also other more sophisticated infrastructure setup such as supporting "Blue/Green" deployment, "Canary" deployment, "A/B" testing, etc.

(if none of these buzzwords make sense, search it. You'll learn a lot! 🤓).

Alternatives to Watchtower

On top of the commercial ones like AWS ECS, Google Cloud Run, etc. - you can use things like Docker Swarm, Kubernetes... Or if you want simpler, there's MicroK8s, k3s, or if you want even simpler... There's making Github actions SSH into your server and run the commands to deploy your app.

But at the end of the day, these are all tradeoffs you gotta make between a number of factors:

Complexity of the infrastructure
Cost
Scalability
Reliability
Maintainability
Security
Performance
Availability
Disaster Recovery

Sometimes if you want to be practical, choose the simplest one that works. A scalable and reliable app is useless if it doesn't have users 😜, so until you have proper users and you really need it to scale... Choose the simplest one that works!

You're done!¶

Congratulations! You've now successfully hosted your app in the internet! 🎉

You can now start to build your own app and host it in the internet!

This is only a start! There's a lot more advanced techniques and concepts to learn about. However, this should give you a good foundation to start building your own app and hosting it in the internet! As any providers such as Heroku, AWS Lightsail, AWS ECS, AWS EKS, or even Kubernetes! All the concepts you learned today, thats what powers those tech!

If you have any questions, feel free to ask!
